Picture of product 05060CV750MFMF5
Check Valve, 2.75" L x 1.38" W x 1.38" H
PARKER part CV750MFMF5
Product ID 05060CV750MFMF5
Call for availability*

*Final pricing and availability will be determined upon request for quote. Volume discounts and other price adjustments may apply.

Description

Hydraulic Check Valve, Pressure - Maximum 3,000 psi, Body Material Steel, Valve Type Check, Port-to-Port Length 2.75 in, Control Direction One-Way, Mounting Screw-In, Reverse Free Flow Reverse Free Flow, Flow Rate - Maximum 65 gpm, Inlet Connection Type JIC 37 Degrees Flare, Inlet Connection Gender Male, Outlet Connection Gender Male, Operating Temperature - Maximum 250 Degrees F, Operating Temperature - Minimum -40 Degrees F, Outlet Connection Type JIC 37 Degrees Flare
